Audit Checklist: 10 Points Your Auditor Will Examine in Screwdriving Processes

Imagine an auditor shows up on your production floor tomorrow morning and asks for the MFU report for your Category A torque tools. Can you put it on the table within two minutes? Or will you still be hunting through five different folders?

Audits in fastening and torque control are getting tougher. Whether it is an IATF 16949 audit in the automotive sector, EN 9100 in aerospace, or a customer audit from a Tier 1 supplier: auditors know exactly where the weak points usually are - and they look for them deliberately. Missing calibration certificates, incomplete process capability records, or undocumented NOK (not OK) processes are classic findings that can lead to expensive rework, blocked deliveries, or even loss of certification.

This article gives you a proven, practical audit checklist with 10 inspection points that auditors regularly scrutinise. For each point, you will learn what the auditor specifically wants to see, where typical weaknesses lie, and how to protect yourself in a systematic way to strengthen your assembly quality assurance and assembly inspection.

The 10 inspection points in detail

Inspection point 1: Fastening case classification according to VDI/VDE 2862

What the auditor wants to see: A complete, up-to-date list of all fastening cases in your assembly - classified as Category A (safety-critical), Category B (function-critical) and Category C (non-critical) in accordance with VDI/VDE 2862.

Typical weakness: The classification was performed once but never updated - even though components, designs or safety requirements have changed. Or: New fastening locations were introduced but never classified.

How to safeguard yourself:

• Maintain a fastening-case matrix with component reference, category, date of last review and responsible person.
• Define a process that automatically triggers a re-evaluation whenever there are design changes.
• The classification is the basis for all further requirements - this is where you should invest particular care.

Inspection point 2: Tool qualification

What the auditor wants to see: Evidence that the torque tool used for each fastening case category is technically suitable and approved. For Category A joints, this means torque and angle measurement, defined tolerance monitoring and shut-off control - in other words, a fully capable angle torque meter based system.

Typical weakness: A simple torque wrench without angle measurement is used for Category A fastening cases - an obvious nonconformity.

How to safeguard yourself:

• For each fastening point, record the approved torque tools with model designation and serial number.
• Ensure that Category A joints are processed with tools that monitor both torque and angle - such as the modular OPERATOR® production tools from GWK with their interchangeable square drive system.

Inspection point 3: Proof of calibration

What the auditor wants to see: Current, valid calibration certificates for every torque tool used in the process - showing validity date, test laboratory name and, for high requirements, the DAkkS accreditation mark.

Calibration certificates or test reports must bear the accreditation mark of the national accreditation body to demonstrate traceability to national standards.

Typical weakness: Expired certificates, calibration performed by non-accredited laboratories or missing traceability to national standards. Especially critical: the tool was repaired in the meantime but not recalibrated afterwards.

How to safeguard yourself:

• Use a digital calibration calendar system that automatically reminds you of upcoming due dates.
• For Category A and B applications, rely on DAkkS-accredited calibration. GWK's own DAkkS-accredited calibration laboratory - a fully fledged DAkkS calibration laboratory - offers class 0.2 measurement accuracy, also as a mobile service directly in your production to minimise downtime.
• The DWPM-1000® calibration devices from GWK additionally enable internal quick checks between calibration cycles to detect deviations at an early stage and support ongoing torque analysis.

Inspection point 4: Machine capability (MFU)

What the auditor wants to see: Current MFU reports according to VDI/VDE 2645-2 for all tools requiring qualification - including statistical parameters such as Cm and Cmk values.

The machine capability study (MFU) determines key figures for the stability and reproducibility of the process influence "machine" and ensures that only suitable torque tools are used.

The required minimum Cmk value is Cm/Cmk ≥ 1.67 for tools used in Category A and B applications.

Typical weakness: The MFU was carried out once during commissioning but never repeated. Or: The test was performed under idealised laboratory conditions and does not reflect the real production environment.

How to safeguard yourself:

• Define intervals for repeating MFUs (e.g. every six months or after maintenance/repair).
• With the QUANTEC MCS® analysis tool from GWK, you can perform MFUs directly on the assembly line - the reference-free angle measurement provides precise Cm/Cmk evaluations that can be exported instantly into professional MFU reports for your assembly inspection documentation.

Inspection point 5: Process capability (PFU)

What the auditor wants to see: Regular PFU evaluations according to VDI/VDE 2645-3 with documented Cp and Cpk values - as proof that not only the tool, but the entire fastening process under real conditions is under control.

While the MFU considers tool capability in isolation, the PFU evaluates the complete process under real production influences - including people, material, method and environment.

Typical weakness: PFU is confused or equated with MFU. Many plants have MFU reports but no separate PFU evidence.

How to safeguard yourself:

• Carry out PFUs at defined intervals - at least once a year and immediately after any process changes.
• The QUANTEC MCS® system (often referred to simply as Quantec MCS in practice) supports you in data acquisition for PFU: WLAN data transmission, automatic logging and export functions for statistical evaluation via Ceus or QS-Torque software, forming a solid basis for assembly quality assurance.

Inspection point 6: Torque documentation

What the auditor wants to see: A complete, tamper-proof record of all torque values - including timestamp, tool ID and component reference.

Typical weakness: Paper-based documentation with illegible entries, missing timestamps or unclear assignment to specific components. Or: Data is recorded but never archived.

How to safeguard yourself:

• Digital tools with automatic data storage eliminate input errors and gaps and are ideal for modern torque control and torque analysis.
• The OPERATOR® from GWK transmits all fastening data via WLAN in real time and stores it with timestamp, parameters and tool identification - always ready as audit evidence for your audit checklist.
• Ensure that your retention periods comply with the relevant standards (IATF 16949 typically requires 15 years for safety-critical joints).

Inspection point 7: Angle documentation

What the auditor wants to see: For Category A joints, not only the torque value but also the angle value - fully captured and documented.

If an angle-controlled tightening strategy is used, a capability study must be performed for this as well.

Typical weakness: Torque is recorded but angle is not - even though the fastening strategy (e.g. yield-controlled tightening) defines angle as a critical control variable.

How to safeguard yourself:

• For each Category A fastening point, check whether the tightening strategy requires angle measurement.
• QUANTEC MCS®, with its reference-free angle measurement, captures torque and angle simultaneously and without gaps - including complete tightening curves for later evaluation with an advanced angle torque meter function.

Inspection point 8: Traceability

What the auditor wants to see: The ability to assign every fastening operation clearly to a specific component or serial number - and to prove this assignment afterwards. This is a core requirement for robust production traceability.

Typical weakness: Fastening data is recorded only with shift date and tool number - but without component reference. In the event of a recall, targeted containment is almost impossible.

How to safeguard yourself:

• Integrate barcode or RFID readers into your fastening process to identify components automatically.
• The OPERATOR® from GWK supports optional barcode readers and can be integrated seamlessly into higher-level MES or ERP systems via Open Protocol and PLC interfaces, strengthening your production traceability.
• Define: Which data must be archived? Who has access? For how long?

Inspection point 9: Training records

What the auditor wants to see: Documented proof that all operators who use torque tools are demonstrably trained and qualified for their tasks.

All activities related to fastening processes must be carried out by demonstrably qualified personnel.

Typical weakness: Training sessions took place, but there are no training records or participant lists. Or: New employees were trained on the job, but this was never documented.

How to safeguard yourself:

• Maintain a training matrix showing for each operator: Which tools and procedures are approved? When was the last training completed? When is the next one due?
• Keep training records with date, content, trainer and the participant's signature.

Inspection point 10: Error management (NOK process)

What the auditor wants to see: A documented, binding process for cases where a fastening is evaluated as NOK (not OK) - with clear rules for blocking, rework and escalation.

Typical weakness: There are informal rules ("the shift supervisor takes care of it"), but no written work instruction. In the audit, it is then impossible to prove what happened to an NOK component.

How to safeguard yourself:

• Define in writing: What counts as NOK? Who decides on release, blocking or rework? How is this documented?
• Ensure that NOK events are archived in a traceable way - including the actions taken and the final report.
• Digital tools such as OPERATOR® can automatically flag NOK fastening cases and trigger a rework request before the component leaves the station.

Requirements by fastening case category: Overview

Not all 10 inspection points apply with the same binding force to every fastening case category. The following table summarises the requirements specified by VDI/VDE 2862:

Test your audit readiness

How well are you prepared for the next audit in fastening technology? Answer the 10 questions in our interactive self-check and get an immediate assessment of your audit readiness for an IATF 16949 audit or any customer-specific audit.

Why digital tools make the difference in audits

A common thread runs through all 10 inspection points: documentation, documentation, documentation. The auditor can only check what is verifiable. This is exactly where digital precision tools have a structural advantage over analogue solutions.

Manual documentation involves three classic risks:

• Human input errors (wrong values, missed entries)
• Media breaks (paper -> Excel -> database) with transfer errors
• Missing or incomplete timestamps and component assignment

The GWK tool system addresses these risks systematically and supports modern assembly quality assurance:

For companies that do not have a permanent need for high-precision analysis tools, or that need to act at short notice before an audit, GWK offers a flexible alternative with the ToolRent® rental system: calibrated QUANTEC MCS® devices, DWPM-1000® units and OPERATOR® tools on demand - with no capital investment.

The 5 most common audit findings in fastening technology

From day-to-day practice we know the findings that crop up again and again. Prepare for them specifically:

1. Expired calibration certificates - the most common and easiest finding to avoid
2. Missing MFU reports after tool repair or tool change
3. Incomplete angle documentation for Category A joints
4. Non-verifiable traceability - fastening data without component reference
5. No written NOK process in place

Conclusion: Preparation beats improvisation

An audit in fastening technology is not a surprise - the inspection points are known and the standards are clear. What makes the difference is the consistency and system with which you document and maintain your processes and torque control.

Go through these 10 points as an internal checklist before the auditor arrives. Identify gaps deliberately and close them - ideally with tools and systems that generate documentation not as extra work, but as an automatic result of every fastening operation.

Together, we develop the optimal solution for your specific audit requirements - from DAkkS-accredited calibration in our DAkkS calibration laboratory, through MFU/PFU support with Quantec MCS, to fully integrated documentation systems for production traceability and assembly inspection. Made in Germany. Engineering with passion.
